Motherboard Intel® S5550
Compact Mehlowserver board w/ up to 4x GbELOM in μATX form factor for entry server applications
Model Name : Intel S5550
Chipset : Intel® C242 PCH
Memory
- • (4) DDR4 DIMM slots (2x memory channels)
- • Support up to 64GB UDIMM DDR4 2666/2400/2133 memory w/ ECC
PCI Expansion Slots
- • (1) PCIe G3 x16 slot (w/ x8 link) (#7)
- • (1) PCIe G3 x8 slot (#6)
- • (1) PCIe G3 x8 slot (w/ x2link) (#5)
Network
- • (4) 1000Base-T ports (4x Intel® i210-AT) (4N SKU), or
- • (2) 1000Base-T ports (2x Intel® i210-AT) (2N SKU)
- • (1) 1000Base-T dedicated IPMI port (RealtekRTL8211E-VB-CG)
Storage
- (6) SATA 6G ports w/ Intel® RSTe4.7 RAID support
